Capable of measuring AC, DC and pulse signals.
Strong interference immunity with high CMRR.
Low drift, fast response , wide bandwidth.
Non-invasive through-hole design (zero insertion loss).
AC variable frequency drive systems.
Servo motor traction control.
Uninterruptible power supplies (UPS).
Welding equipment & battery power systems.
@TA=25℃,unless otherwise stated.
| Type | TR0215A-LBH24 | ||
|---|---|---|---|
| IPN | Primary Rated Input Current | DC 200A | |
| IP | Primary Current Measurement Range | DC 0~240A | |
| VSN | Secondary Rated Output Voltage | DC 10V | |
| UC | The Power Supply Voltage | DC +24V | |
| Power | 0.5W | ||
| X | Accuracy | ±1% | |
| BW | Frequency Bandwith | DC~20kHz | |
| Overload Capacity | 10 times | ||
| Ud | Power Frequency Withstand Voltage | 5kV AC/1min | |
| Tr | Response Time | ≤10μs | |
| V0 | Offset Voltage | ≤30mV | |
| Temperature Drift | Maximum ≤±0.8%/°C | ||
| TA | Ambient Operating Temperature | -25℃~+70℃ | |
| TS | Ambient Storage Temperature | -40℃~+85℃ | |
